Movable / Stationary
Performance: 110 tons / hour
Mixer volume: 1500 kg
Number of containers: 3 х 30 m3
Power unit blocks quantity: 5
Number of fractions: 4
Unit of average productivity.
The price of the asphalt mixing plant KDM 201 is available upon request.
If you have any questions, please contact our consultants by e-mail or leave your phone number and we will call you back.
|Productivity is nominal at humidity of input materials (sand and crushed stone) up to 3%, t/h||110|
|Installed capacity, kW, max.||330|
|Capacity of the power unit bunkers, pcs* m3||5х8=40 *|
|Feeder type||belt, adjustable|
|Feeder speed control range||1:20|
|Conveyor belt width, mm||500|
|Drying drum, diameter x L, mm||1800х7900|
|Drying drum drive||adjustable, with smooth start and speed change|
|Type of fuel||at option: liquid or gaseous|
|Number of fractions of the dosed stone material, pcs.||4 *|
|Capacity of hot stone materials bunker, m3||19|
|Maximum mass of batch, kg||1500|
|Type of mixer||batch action|
|Time of one batch preparation, sec.||45..60|
|Total capacity of ready mix bunker, t (m3)||72 (39) *|
|Method of ready mix loading into the vehicle -||from the mixer or the finished mixture aggregate|
|Availability of the infrared pyrometric sensor for asphalt temperature monitoring||available|
|Mineral powder bin capacity, m3||32,5 *|
|Dust bin capacity, m3||26|
|Total capacity of tanks for bitumen, m3||90 *|
|Type of dust collecting device||on option: bag filters or combined: dry (cyclones), wet (scrubber "Venturi")|
|Batcher type||weighing on strain gauges|
|Actuating mechanisms drive||electropneumatic|
* completeness of units in accordance with agreement with the customer
Delivery of plants can be carried out by rail, road and sea transport.
The quality of asphalt-mixing plants (products) manufactured by PJSC "Kredmash" is in accordance with GOSTs and technical specifications and is confirmed by the acceptance of the manufacturer's QC department.
Guarantee service life of asphalt-mixing plants is 12 months; it is calculated from the date of commissioning, but no more than 15 months from the date of delivery of the Product by manufacturer provided that the rules specified in the operating manual are observed.
The warranty does not apply to the Products in the event of non-compliance with the rules specified in the operating manual of the Products, as well as in the case of constructive changes made without agreement with the Seller.
The Seller is not responsible for the warranty obligations if the Product is put into operation by specialists not certified by PJSC "Kremenchug plant of road machines".
When installing and launching the Product, the specialists of PJSC "Kremenchug plant of road machines" are issued warranty and Service Book, which is the basis for the fulfillment of warranty obligations.
